The SWU series is a high-precision industrial grade time difference ultrasonic flowmeter. It adopts the latest industrial grade FPGA chip with 700000 gate arrays, greatly improving signal sampling frequency and bubble tolerance. The independently developed TGA technology enables it to handle more complex logic and operations, achieving more accurate and faster measurements. Enable the flowmeter to withstand discontinuous bubbles or impurities for 5 seconds.
At the same time, it has the characteristics of simple installation and convenient use of ultrasonic flow meters, and can be installed without breaking pipes or stopping water and work.
Easy and convenient installation, high flexibility, and a pair of sensors can be used for all pipe diameters.
High precision (± 0.5%), high response speed (sampling speed can reach 300 times/second), and low flow rate measurement (maximum flow rate can reach 0.03 meters/second).
A single medium can be used for measurement and can be widely applied in fields such as water treatment, pure water, ultrapure water, petroleum and chemical industries, and energy-saving air conditioning.
The standard plug-in sensor has a maximum temperature limit of 130 ℃, while the high-temperature sensor has a maximum temperature limit of 180 ℃.
It can be used in conjunction with RTD models and temperature sensors to become an energy meter for measuring the heat and cooling consumption of heating pipelines and air conditioning refrigeration pipelines.
-
Applications
-
Basic Parameters
-
Dimensions
-
model
-
Request a Quote
-
Related Products
APPLICATIONS
-
-
Petrochemical industry -
Water treatment -
Intelligent building
BASIC PARAMETERS
| Model | SWU901 | SWU801 |
| Measurement medium | Single medium acoustic liquid | |
| Measuring range | ±0.01m/s ~ ±12m/s | ±0.03m/s ~ ±5m/s |
| Accuracy | 0.5% | 1% |
| Repeatability | 0.1% | 0.2% |
| Measure the pipe diameter | 15mm~5000mm(Products below 25mm are customized, please contact us) | 15mm~1200mm(Products below 25mm are customized, please contact us) |
| Output | Analog output: 4~20mA, maximum load 750 Ω Pulse output: 0~9999Hz, OCT，（min.and max. frequency is adjustable） Relay output: SPST， Maximum 1Hz（ 0.4A@125VAC 2A@30VDC ） | Analog output: 4~20mA, maximum load 750 Ω Pulse output: 0~10KHz |
| Communication | RS232 & RS485 Modbus | |
| Storage | TF card (expandable to 32GB, note: sending data every 60 seconds can last for 12 years) | |
| Power supply | 90~245VAC, 48~63Hz, 10~36VDC | 10~36VDC/1A |
| Display | 240*128LCD | 240*128LCD |
| Operation temperature | Transmitter: -20 ℃~60 ℃ Sensor: -40 ℃~80 ℃, standard type -40 ℃~180 ℃, high temperature type | Transmitter: -20 ℃~60 ℃ Sensor: -40 ℃~75 ℃, standard type |
| Measurement environment | Relative humidity 0-99%, non condensing | Relative humidity 0-99%, non condensing |
| Protection grade | Transmitter IP65, sensor IP68 | Transmitter PC/ABS IP65, sensor IP68 |
| Cable | Twisted shielded cable, with a standard length of 9 meters, can be extended to 274 meters. | Twisted shielded cable, with a standard length of 9 meters, can be extended to 274 meters. |
| Model | SWU811 |
| Pipe diameter range | DN15~DN65 |
| Supported pipeline materials | Metal/PVC, PP or PVDF hard plastic pipes |
| Supported liquid media | Water/Other (single without solid particles and impurities) |
| Supported medium temperature | 0-115 ℃ (no freezing on the surface) |
| Default low flow rate cut-off value | 0.1m/s |
| Display mode | 256 * 128 backlit LCD |
| Response time | 0.5~60 seconds |
| Accuracy class | ± 2%, can reach ± 1% after calibration |
| Data storage cycle | 300 milliseconds |
| Memory backup | EEPROM (data storage length: over 10 years, data read/write frequency: over 1 million times) |
| Power and I/O connectors | M12 aviation plug |
| Output | 4-20mA |
| Communication | ModbusRS485 |
| (Optional output) | OCT (pulse output)/one relay alarm (please contact the factory for details) |
| Power supply | 10-24VVDC |
| Electric power | Less than 3W |
| Protection circuit | Power reverse protection, power surge protection, short circuit protection for each output, surge protection for each output |
| Shell protection level | IP65 |
| Ambient temperature | -10 to 60 °C (no freezing) |
| Relative humidity | 35 to 85% RH (non condensing) |
| Vibration resistance | 10 to 55Hz, double amplitude 1.5mm, 2 hours on each XYZ axis |
| Impact resistance | 100m/s 216ms pulse, 1000 times on each of the X, Y, and Z axes |
| Material of the whole machine | Aluminum alloy, industrial plastic |
| Cable Length | Comes standard with 2 meters, (PT1000 comes standard with 9 meters) |
| Model | SWU821 |
| Measuring range | ±0.03 ft/s ~±40 ft/s(±0.01m/s~±12m/s) |
| Accuracy | ±1% |
| Pipe diameter range | 1/2"~48"(15mm~1200mm) |
| Measurement medium | Single sound conducting liquid medium |
| Measurable pipes | Carbon steel, stainless steel, PVC pipe or other dense sound conductive pipe materials |
| output | Analog output: 4-20mA, maximum load 750 Ω Modbus:RS485 |
| SD card storage | 32G |
| Storage time interval setting | 1~99999 seconds |
| Keyboard | Digital film button |
| Display | 240 * 128 LCD display screen (with backlight) |
| Power supply | Rechargeable lithium battery with a capacity of 3000mAh. Under normal usage, a full charge can last for 16 hours. |
| Operation temperature | Transmitter: -20 ℃~60 ℃ Sensor: -40 ℃~80 ℃, standard type- 40 ℃~130 ℃ is optional |
| Measure the relative humidity of the environment | Relative humidity 0-99%, non condensing |
| Protection grade | Transmitter IP54, sensor IP68 |
| Cable | Twisted shielded cable, standard length is 5 meters |
